The CP100 is a 240V control panel with up to 100 Amps total output capability. It has multiple controller options and can work for a variety of applications.
Please see CP series basic control panel model comparison guide here.
Feature:
- Four output channels. 240V/30A max each channel. Total output capacity is 100A.
- Enclosure with 5 x 1/2" EMT for easy connection.
- Two PID controllers. Controller #1 is for main temp control. Controller #2 is for high temp limit control (SYL-2362, see note 6 below).
- Controller with either PID algorithm or artificial intelligence algorithm.
- Two line display that shows both the set temperature and actual monitoring temperature.
- Displays temperature in either Fahrenheit or Celsius.
- Mini 2-in-1 Volt and Amp meter for displaying system power level.
- Solid State Relay (SSR) for long lasting, fast and noise free power switching.
- Contactor for completely cut off power to the element.
- Strain-relief power cord connector for hard-wiring the power line.
- Assembled in U.S.
- US seller & US support team. This control panel is designed and manufactured by Auber Instruments. Copyright © Auber Instruments.
Controller module options:
Power input & output connection options:
By default, power input & output cords need to be hardwired into this control panel. If you need a power output socket instead, please contact us.
Temperature sensor for thermometer:
This panel requires
two temp sensors. Default sensor connection option is hardwiring. If you need detachable receptacles for the sensors on the bottom of the panel, please select the
thermocouple socket (type K, mini) or
XLRCON-M (PT100 RTD). For the difference between thermocouple and RTD, please see help center article
here. For over applications,
TC-K3MM (thermocouple) is recommended (Max temp 900F). No sensor nor sensor cable is included with this panel.
CP100 control panel with SYL-2352 and SYL-2362 installed
Specifications
| Heater Control Output |
30A, 240VAC maximum/channel. 4 channels in total |
| Input Connection |
100A |
| Sensor |
2 x K Type Thermocouple sensor (not included) |
| Circuit Breaker |
2P 125A. |
| Temperature Controller |
See option above |
| Thermometer |
SYL-2362 (readout, limit control only) |
| Dimension (W x H x D) |
16 x 12 x 8 inch (40 x 30 x 20 cm) |
| Weight |
30 lb (12.7 kg) |
| Warranty |
One (1) year limited warranty. See here for details |
Important notes:
- The control panel is designed for 240V single phase power. Please verify your power supply before purchase.
- This control system is designed for heating elements (resistive load) only, not for gas burners nor propane heaters. If you want to use the system for a gas burner or other types of heater, please contact us before purchase; otherwise, your purchase may not be covered by our warranty.
- This control panel has four output channels. Each channel is rated 30A max. Total is 100A max. This control panel cannot drive one single element over 30A.
- Environment humidity is less than 85% RH.
- Heating element is not included.
- Input power cord (AWG 2/4) is not included because each user may have different hook up requirements. Non-UL AWG2/4 with max OD 30mm is required. Reference #1, Reference #2.
- The additional SYL-2362 thermometer (right) is used to monitor the temperature for over-temperature safety protection. It can provide with a secondary sensor temp readout. In the case if the main PID (such as SYL-2352) or sensor is failed, the SYL-2362 and its sensor can be programmed to shut off power to all elements if oven temperature goes too high (limit control protection).
- Warranty: One (1) year limited warranty.
- Lead time for this product is 4-5 business days. Please contact us if you have any other questions.
- If you plan to use this control panel for a larger oven which is over its limit, you may consider using a auxiliary control panel together with this panel. See CP30-PCO and CP50-PCO for details.
