The CP75 is a 240V control panel with up to 75 Amps total output capability. It has multiple controller options and can work for a variety of applications.
Please see CP series basic control panel model comparison guide here.
Feature:
- Three output channels. 240V/30A max each channel. Total output capacity is 75A.
- Enclosure with 4 x 1/2" EMT for easy connection.
- One controller with either PID algorithm or artificial intelligence algorithm.
- Two line display that shows both the set temperature and actual monitoring temperature.
- Displays temperature in either Fahrenheit or Celsius.
- Mini 2-in-1 Volt and Amp meter for displaying system power level.
- Solid State Relay (SSR) for long lasting, fast and noise free power switching.
- Contactor for completely cut off power to the element.
- Strain-relief power cord connector for hard-wiring the power line.
- Assembled in U.S.
- US seller & US support team. This control panel is designed and manufactured by Auber Instruments. Copyright © Auber Instruments.
Controller module options:
Power input & output connection options:
By default, power input & output cords need to be hardwired into this control panel. If you need a power output socket instead, please contact us.
Temperature sensor for thermometer:
This panel requires
one temp sensor. Default sensor connection option is hardwiring. If you need a detachable receptacle for the sensor on the bottom of the panel, please select the
thermocouple socket (type K, mini) or
XLRCON-M (PT100 RTD). For the difference between thermocouple and RTD, please see help center article
here. For over applications,
TC-K3MM (thermocouple) is recommended (Max temp 900F). No sensor nor sensor cable is included with this panel.
CP75E control panel with SYL-2352 installed
Specifications
| Heater Control Output |
30A, 240VAC maximum/channel. 3 channels in total |
| Input Connection |
75A |
| Sensor |
1 x K Type Thermocouple sensor (not included) |
| Circuit Breaker |
2P 100A. |
| Temperature Controller |
See option above |
| Dimension (W x H x D) |
16 x 12 x 8 inch (40 x 30 x 20 cm) |
| Weight |
28 lb (12.7 kg) |
| Warranty |
One (1) year limited warranty. See here for details |
Important notes:
- The control panel is designed for 240V single phase power. Please verify your power supply before purchase.
- This control system is designed for heating elements (resistive load) only, not for gas burners nor propane heaters. If you want to use the system for a gas burner or other types of heater, please contact us before purchase; otherwise, your purchase may not be covered by our warranty.
- This control panel has three output channels. Each channel is rated 30A max. Total is 75A max. This control panel cannot drive one single element over 30A.
- Environment humidity is less than 85% RH.
- Heating element is not included.
- Input power cord (SOOW 4/4) is not included because each user may have different hook up requirements.
- Warranty: One (1) year limited warranty.
- Lead time for this product is 4-5 business days. Please contact us if you have any other questions.
- If you plan to use this control panel for a larger oven which is over its limit, you may consider using a auxiliary control panel together with this panel. See CP30-PCO and CP50-PCO for details.
This product was added to our catalog on Friday 24 April, 2026.
