External-Mount Heat Sink for 40A Linear SSVR / 25A 3-Phase SSR

The external mounted heat sink eliminates the venting requirement of the enclosure for internally mounted heat sink. It is more efficient and keeps the internal of the controller box free from the dust. This sink come with pre-drilled and tapped mounting holes for one 3-phase SSR. This heat sink can be used with one 40A linear SSVR (SSVR40A-LIN), or one 3-Phase SSR if your actual load is 25A or less per phase.

Mounting screws (8 x M4) and thermal conductive grease are included. The heat sink is shipped with SSR mounting screws and heat conductive grease.

Dimensions:

Base: 104x175 mm
Height 25 mm
