WIFI BBQ Temp Control Kit with 20CFM blower, 3-Probe, 2nd Gen.

This PID controller set is for controlling the temperature of a medium to large size backyard smoker, a 55-gallon drum-style smoker, or an off-set type smoker. This system contains a 20 CFM blower that is more powerful than the other system we offer.

Auber’s SYL-3615 Wi-Fi BBQ controller is our newly released BBQ controller on November 2020 with two major changes:

• A new Wi-Fi module that allows push-notification, OTA updates, and many other potentials. Compatible with mesh routers.
• The total number of probes has been increased from 2 to 3.

With these two hardware changes, we can bring a few great improvements compared to the previous model (SYL-2615):

• Newly added alarm (push) notifications straight to your phone.
• Improved compatibility with Wi-Fi routers.
• Faster data transfers and better Wi-Fi signal reception
• Over-the-air (OTA) update capability. Keeping your device always up to date.
• Accept three temperature probes instead of two. One pit probe and two food probes to ensure an easier experience of monitoring the cooking process.
• 6 cooking profiles and 6 cooking steps in each profile
• More flexibility in controlling the cooking process: starting/stopping the cooking process and/or jumping to a step whenever you want.
• Added secure mounting hooks.

Other than these big improvements, the new SYL-3615 has inherited all the features of its predecessor, the award-winning SYL-2615, which includes:

• The ability to monitor and control the cooking process remotely from your smartphone on the App.
• Well-tuned PID control algorithms that achieve and maintain tight control of the pit temperature.
• A variety of parameters allow users to fine-tune the device per their cooking preferences.
• Able to adjust fan output by either time-proportional control (for fine temperature tuning) or by fan-speed control (for minimizing the ash).
• Automatically detects lid openings and pauses the output.
• Exports/retains cooking temperature statistical data for up to 10 hours.
• Durable temperature probes with stainless steel cables over-braiding and high-temperature Teflon wires (720°F/380°C).

What’s included

•    1 x SYL-3615 controller
•    1 x Pit probe with a mounting clip (WS-SENSOR17)
•    1 x Food probe (WS-SENSOR18A)
•    1 x probe at your choice (either WS-SENSOR18A or WS-SENSOR22)
•    1 or 2 x 20 CFM blower (BL-20)
•    (Optional) 1 or 2 x Ball Valve Adapter.
•    (Optional) 1 x Y-splitter (if you choose 2 x 20 CFM blowers)
•    1 x AC to DC power adapter (12V, 1A) for 1 x 20 CFM blower

Parts included in this set (default package)

Probes in this kit:

Pit probe: WS-SENSOR17. Free hanging design that measures the pit temperature that allows you to control the smoker. (Max temperature: 720°F/380°C)
Meat probe (standard): WS-SENSOR18A. It has an L-shape with a pointed tip. By default probe option, we will ship one sensor18A with a green connector and one sensor18A with a red connector. (Max temperature: 720°F/380°C)
Meat probe (fish probe): WS-SENSOR22. It has a thin and small tip, the sensor22 is suitable for small pieces of meat, such as fish and sausage. (Max temperature: 400°F)

WS-SENSOR18A, food internal probe (max temp. 720°F/380°C)	WS-SENSOR22, miniature food probe, for fish and sausage (max temp. 720°F/380°C)



Blower and Blower Mounting Option:

This control set includes one 20 CFM blower, which is recommended for high-temperature smoking (300F or higher) or extra large-size smokers. To mount this blower to your smoker, you may also need a mounting ball valve adapter.

Ball Valve Adapter for Blower (optional) Showing pictures of adapters for both 6.5 CFM and 10&20 CFM Blowers. The Ball Valve Adapter for 10&20 CFM Blower is suitable for the blower in this kit.

Accessory Option: If you want to use 2 of the 20 CMF blowers, you'll need a Y-splitter cable (DCcord4).

Power Adapter Option: The default power adapter can supply 1A current at 12VDC, enough to drive a 20 CFM blower, which draws about 0.7A at 12VDC. However, if you need to drive 2 of the 20 CFM blower, you'll need a power adapter rated for 2A at 12VDC. This option is not available at this moment. But you can consider PA-DD1 or PA-DD2 if you already have DeWalt battery packs.

Specifications:
